OEM Style Japanese Electrical Harness Wiring  Connector Sumitomo HX - HV/HVG Type .040 - .090

View Cart

2 pin HX .040  Female Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6189-0890 and 6918-1835

This Connector has Center Rib


Waterproof housing with inner seal, and a seal for each wire.


                              Female HX040-2    $3.15 each




Kawasaki 09 ER650 Ninja Coolant Temp Sensor

Honda TRX Fuel pump sending unit.

Honda Grom Fuel injector connector

Honda/Acura Transmission Pressure Switch connector

Sumitomo - HX - HV Sealed - for .040 and .090 Terminals.

These Connector s are used highly on Honda’s TRX, CBR, GL1800, Accord, Civic, and Kawasaki Ninja For wire sizes .6 - 1.3mm (18-22 AWG)

All connectors Come complete with male, female terminals and Wire seals.

More Terminals, seals, and plugs available at the bottom of the page

Add to Cart
Sumitomo HX 040 Series

3 pin HVG .040  Female Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6189-7037 and 6918-1833

This Connector has Top Rib



Waterproof housing with inner seal, and a seal for each wire.


                         Female HV040-3 Tr    $3.95 each



Honda/Acura ignition coil connector

4 pin HV .040  Female Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG)

6189-7039 Japan


Waterproof housing with inner seal, and a seal for each wire.


                             Female HV040-4     $5.55 each





Honda/Acura O2 sensor connector

3 pin HX .040  Female Connector - with Terminals and Seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6189-0887 and 6918-1833

This Connector has Center Rib

Mates with connector below.


Waterproof housing with inner seal, and a seal for each wire.


                                Female HX040-3  $3.95 each



Applications

Some late Model CBR1000 MAP, TPS Sensors

Some late model Honda tail light connectors

Late Model Honda/Acura Crank Angle Sensor Connector

2 pin HX .040 Bottom Rib Female Connector - with Terminals & Seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6189-0891 and 6918-1835

This Connector has Bottom Rib


Waterproof housing with inner seal, and a seal for each wire.


                Female HX040-2 Br Gray   $3.15 each




Honda/Acura Transmission Pressure Switch connector

Add to Cart Add to Cart

2 pin HX .090  Female Connector - with Terminals and seals

Terminals Fit wire size .6 - 1.3 mm (18-22 AWG)

Genuine - Japan




                           Female HX090-2     $3.95 each



Applications include

Fuel Tank/Pump Sending Unit Connector

Honda Linear Control Valve Connector

2 pin HX .090  Female Connector - with Terminals and seals

Terminals Fit wire size .6 - 1.3 mm (18-22 AWG)

Genuine - Japan




                           Female HX090-2B    $5.95 each



Applications include

Fuel Tank/Pump Sending Unit Connector

Honda Linear Control Valve Connector

Sumitomo HX 090 Series
Add to Cart Add to Cart
Extra female Terminal for HX/HV 040 series
8100-3068
FT HX/HV 040  $0.24 each
Fit wire size .5 - 1.3 mm (18-22 AWG)

Add to Cart
Extra female Terminal for HX 090 series


$0.26 each   HX/DL 090-F

Add to Cart Add to Cart
Extra Wire Seal for HX/HV 040 series
7165-0622 Violet
HX 040 Seal $0.15 each
For insulation diameter 1.80-2.20 mm  (18-20 AWG)

Add to Cart
Extra Wire Seal for HX 090 series
Blue Seal For Smaller wire diameter 18-22 awg

$0.17 each   HX/DL 090-S  Seal

Add to Cart

2 pin HX .090  Female Connector - with Terminals and seals

Terminals Fit wire size .6 - 1.3 mm (18-22 AWG)

Genuine - Japan




                            Female HX090-1     $4.15 each





This one is Primarily used as Late Model Honda Car Horn Connector

Add to Cart
Extra Wire Seal for HX 090 series
Brown Seal For Larger wire diameter 14-18 awg

$0.17 each   HX/DL 090-L  Seal

Add to Cart
About Me Kits Crimp tools Terminals Relay kits Relays Shipping Fuse box's Tubing Fuses New Items Connectors Home
Extra male Terminal for HX 090 series


$0.19 each   HX/DL 090-M

Add to Cart

3 pin HX .090  Female Connector - with Terminals and seals

Terminals Fit wire size .6 - 1.3 mm (18-22 AWG)

Genuine - Japan




                             Female HX090-3    $4.95 each



Applications include

Kawasaki Tail light connector

Honda TRX 450 Tail Light Connector

2 pin HX .040 Top Rib Female Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6188-0590

This Connector has Bottom Rib

mating connector for above 2 pin gray female


Waterproof housing with inner seal, and a seal for each wire.


                    Male HX040-2 Br Gray   $3.95 each





2 pin HV .040 Top Rib Female Connector - with Terminals & Seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG)

6189-6905 Japan

This Connector has Top Rib


Waterproof housing with inner seal, and a seal for each wire.


                         Female HV040-2 Tr   $3.45 each




Honda fuel injector connector

Add to Cart

2 pin HX .090  Female Connector - with Terminals, seals, and retainer

Terminals Fit wire size .5 - .85 mm (18-22 AWG)

Genuine - Japan



                            Female HX090-2 FI   $3.95 each



Application - Honda NH-1

Various Honda and Acura Fuel injectors

Suzuki GSXR


2 pin HX .090  Male Connector - with Terminals, and seals

Terminals Fit wire size .5 - .85 mm (18-22 AWG)


Custom manufactured male housing for the above Female connector


Tough waterproof housing with inner seal, and a seal for each wire.


                             Male HX090-2  FI     $3.25 each


Application - Honda NH-1

Various Honda and Acura Fuel injectors

Suzuki GSXR


Add to Cart Add to Cart
HX 090 Series  Honda Fuel Injector Connectors

Economy  - Micro Open Barrel Crimp Tool

For   Sumitomo 090 - 040 Terminals, JAE 040, Insulation and Wire Seals 16 - 30 AWG

Made in USA by Rostra

I have used this and  you can get quality crimps with it. This tool does the wire crimp, then the insulation or wire seal crimps in 2 steps.

If your not doing this type of crimping all the time, great tool to add to your box, and you cant beat the price. Pick up a few extra terminals to practice with.


This will not do Bullet terminals,110, or 250 standard terminals



                                                          $33.95 each   ECT47

Add to Cart
This  HX-040 crimp was done with this tool listed
Using dies A and E
Add to Cart Add to Cart
Full Reels available

3 pin HX .090  Female Connector - with Terminals, seals, and retainer

Terminals Fit wire size .5 - .85 mm (18-22 AWG)

Sumitomo part number 6189-0728 -  Genuine - Japan





                           Female HX090-3 COP   $5.65 each



Honda/Acura K-series and F-series Ignition Coil on plug COP connectors


Add to Cart
HX 090 Series  Honda Ignition Coil Connector

4 pin HV .040  Male Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG)

6188-4776 Japan


Waterproof housing, Terminals, and a seal for each wire.


                                Male HV040-4     $5.25 each





Honda/Acura O2 sensor connector

Add to Cart

5 pin HX .040  Female Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6189-1081 and 6918-2128


Waterproof housing with inner seal, and a seal for each wire.


                             Female HX040-5     $5.75 each





Honda/Acura MAF - Mass Air Flow sensor connector



There is no mating half for this housing

Add to Cart
Extra Male Terminal for HX/HV 040 series
8100-3178
MT HX/HV 040  $0.22 each
Fit wire size .5 - 1.3 mm (18-22 AWG)

Add to Cart
Full Reels available

6 pin HV .040  Male Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6188-4908


Waterproof housing, Terminals, and a seal for each wire.


                                Male HV040-6     $6.25 each





Honda/Acura Air/Fuel Ratio - AFR Sensor Connector

Honda Motorcycle Tail light Connector

Add to Cart

3 pin HV .040  Male Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6188-4775

This Connector has Top Rib

Mates with above HVG-3 female


Waterproof housing with inner seal, and a seal for each wire.


                             Male HV040-3 Tr    $4.25 each

Add to Cart

2 pin HX .040  Male Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6188-0589

This Connector has Center Rib


Waterproof housing with inner seal, and a seal for each wire.


                                 Male HX040-2    $3.65 each





Honda Grom Fuel injector connector

Add to Cart
Dummy Plug for HX/HV 040 series
7165-0432
HX 040 Plug  $0.25 each


Add to Cart
New Photo coming soon!!

6 pin HX .040  Female Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6189-1012 and 6918-2056


Waterproof housing with inner seal, and a seal for each wire.


                             Female HX040-6     $5.85 each




2008-2011 Honda CBR - Ignition Coil Harness Connector

Add to Cart

6 pin HX .040  Male Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6188-0658


Waterproof housing with inner seal, and a seal for each wire.


                                 Male HX040-6     $5.75 each




2008-2011 Honda CBR - Ignition Coil Harness Connector

Add to Cart

These Connectors are used on many makes and models including Honda, Toyota, Suzuki, and Kawasaki for Fuel injectors, Cam and Crank angle sensor connector, ignition coil connectors, speed sensor connector, Vtec pressure switch connectors, O2  and air/fuel sensor connectors, purge control valve connector, MAF sensor connector, transmission linear solenoid valve connector, transmision clutch pressure switch connectors, and much more. 6189-7036, 6189-7037, 6189-7037, 6189-7038, 6189-7039, 6189-7040, 6189-0940, 6189-6902, 6189-6904, 6189-6905, 6189-6907, 6189-6908, 6189-0890, 6189-0887, 6188-4739, 6188-4739, 6188-4908, 6189-1081, 6189-0891, 6918-1835, 6189-0593, 6189-0552, 6189-0596, 6918-1371, 6189-0591, 6918-1370, 6918-1260, 8100-3068, 8100-3067, 8100-3178, 8100-3177, 7165-0621, 7165-0622, 7165-1075, 6189-1012, 6918-2056, 6189-1081, 6188-0658.

All connectors Come complete with male, female terminals and wire seals.


3 pin HX .040  Male Connector - with Terminals and Seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6188-4739

This Connector has Center Rib

Mates with connector above.


Waterproof housing with inner seal, and a seal for each wire.


                                Male HX040-3      $5.95 each



Applications

Some late Model CBR1000 MAP, TPS Sensors

Some late model Honda tail light connectors

Add to Cart

3 pin HX .090  Female IAC Connector - with Terminals and seals

Terminals Fit wire size .6 - 1.3 mm (18-22 AWG)

Genuine - Japan




                       Female HX090-3 IAC   $7.95 each NO STOCK!!


                                                          Use MT090-3E


Applications include

Honda IAC - Idle air control valve connector

Limited Quantity Available

4 pin HV .040  Female Connector keyed with bottom rib

- with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG)  Japan


Waterproof housing with inner seal, and a seal for each wire.


                          Female HV040-4 Br   $5.95 each



I do not have a mating connector for this one.


O2 sensor connector

Add to Cart

6 pin HV .040  Female Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6189-4070


Waterproof housing, Terminals, and a seal for each wire.




                           Female HV040-6      $6.80 each





Honda/Acura Air/Fuel Ratio - AFR Sensor Connector

Honda Motorcycle Tail light Connector

Add to Cart
Extra Wire Seal for HX/HV 040 series
7165-0621 Light Green
HX 040 Seal $0.17 each
For insulation diameter 1.60-1.90 mm (18-24 AWG)

Add to Cart Cavity plug for HX/DX/HW 090 series

$0.15 each   HW/HW 090 Plug


Add to Cart
Crimp tool can be found at the bottom of page

5 pin HV .040  Female Connector - with Terminals and seals

Terminals Fit wire size .5 - 1.3 mm (18-22 AWG) Japan

6189-6909 and 6918-2128


Waterproof housing with inner seal, and a seal for each wire.


                            Female HV040-5     $5.65 each







There is no mating half for this housing

Add to Cart Add to Cart
